MIL-PRF-49450-8 Battery, Rechargeable, Nickel-Cadmium, Vented, Aircraft, Bb-716/A

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8


MIL-PRF-49450/8A(CR)
RECEPTACLE
BATTERY CASE VENT
MS3509-28
0.608 + .008 OD
0.375 + .031 ID
(AFTER FLUIDIZATION)
RECEPTACLE
MS3474L12-10PN
IDENTIFICATION
MARKINGS
3.828 + .062
INSTRUCTION
WARNING
MARKINGS
MARKINGS
10.796 + .062
11.371 + .062
SIDE VIEW
C
L
CONNECTOR MARKINGS
WITHIN .060
4.756 +.062
J2
J1
1.125 MAX
4.542
.800 +.030
+.062
FRONT VIEW
49450-3
FIGURE 2. Markings and dimensions of battery
(front and side views).
2
