INCH-POUND
MIL-PRF-49450/8A(CR)
9 October 1997
SUPERSEDING
MIL-B-49450/8
16 January 1987
w/AMENDMENT 3
3 September 1992
PERFORMANCE SPECIFICATION SHEET
BATTERY, RECHARGEABLE, NICKEL-CADMIUM, VENTED, AIRCRAFT, BB-716/A
This specification is approved for use within CECOM, Department of the Army, and is available
for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-PRF-49450 listed in that issue of the Department of Defense Index of
Specifications and Standards (DoDISS) specified in the solicitation.
1.00 +.25 RIVETED or WELDED PORTION
5 . 0 0 +.25
OF CARRYING STRAP, 2 PL
1.0 WIDE WEB NYLON
SCHEMATIC DIAGRAM
CARRYING STRAP, 9.5
(THIS SIDE OF CASE)
TOTAL LENGTH
C
L
5.578 +.020
W ITHIN
.060
. 3 7 5 + .031
6.578 MAXIMUM
4.625
+.031
11.214 MAXIMUM
49450-3
FIGURE 1. Markings and dimensions of battery (top view).
AMSC N/A:
1of 8
FSC 6140
DISTRIBUTION STATEMENT A: Approved for public release; distribution is unlimited.
