MIL-PRF-8565/13A
10.5
128.2 MAX
± 1.5
OF RECEPTACLE AND CASE
POLARITY MARKING (SEE 3.6.2)
RECEPTACLE (SEE 3.5.5)
MARKING
LABEL
5.6 ± 0.1 DIA X 11.1 DEEP MIN
NO. 3
GUIDE HOLES (2 PLACES) MAY
BE FREE OF PAINT
159.5
MAX
3.2 ± 0.1
P1
6.9 ± 0.2
OF RECEPTACLE
MOUNTING HOLES
52.4 ± 0.1
104.8 ± 0.1
123.8 ± 0.7
REAR VIEW
FIGURE 1. PIN D8565/13-1 dimensions.
