MIL-PRF-49450/5B(CR)
TABLE I. Reference wire listing for figure 1.
REF LTR
WIRE DESCRIPTION
A
WIRE, BLUE TO PIN C, 18 INCHES LONG
B
WIRE, GREEN TO PIN H, 16.5 INCHES LONG
C
WIRE, WHITE, 2.5 INCHES LONG
D
WIRE, WHITE TO PIN E, 14 INCHES LONG
E
WIRE, WHITE TO PIN F, 12 INCHES LONG
F
WIRE, YELLOW TO PIN A, 10 INCHES LONG
G
WIRE, YELLOW TO PIN B, 10 INCHES LONG
H
WIRE, ORANGE TO PIN K, 10 INCHES LONG
I
WIRE, ORANGE TO PIN J, 10 INCHES LONG
J
WIRE, RED TO PIN G, 6 INCHES LONG
K
WIRE, BLACK TO PIN D, 6 INCHES LONG
TABLE II. Reference wire listing for figure 2.
REF LTR
WIRE DESCRIPTION
WIRE, BLUE TO PIN C, 16.0 ± .50 INCHES LONG FROM L TO O
A
WIRE, GREEN TO PIN H, 15.3 ± .50 INCHES LONG FROM L TO P
B
C
WIRE, WHITE AS REQUIRED
WIRE, WHITE TO PIN E, 14.38 ± .5 INCHES LONG FROM L TO Q
D
WIRE, WHITE TO PIN F, 14.38 ± .50 INCHES LONG FROM L TO Q
E
WIRE, YELLOW TO PIN A, 9.12 ± .50 INCHES LONG FROM L TO N
F
WIRE, YELL TO PIN B, 9.12 ± .50 INCHES LONG FROM L TO N
G
WIRE, ORANGE TO PIN K, 9.12 ± .50 INCHES LONG FROM L TO N
H
WIRE, ORANGE TO PIN J, 9.12 ± .50 INCHES LONG FROM L TO N
I
WIRE, RED TO PIN G, 6.50 ± .50 INCHES LONG FROM L TO M
J
WIRE, BLACK TO PIN D, 6.50 ± .50 INCHES LONG FROM L TO M
K
3
