MIL-PRF-49450/7B(CR)
DRAWING NOTES:
1. All dimensions shown in figure are in inches, unless specified otherwise.
2. The cell shall use two threaded stud type terminals.
3. Per stud terminal - 10-32, 5/16 inch hexagonal nuts and one Belleville spring.
4. The positive half of the cell cover shall be permanently dyed red. Minimum width of
red band shall be no less than 0.5 inches.
5. Position of the cell label is optional.
6. The manufacturer's name or symbol shall be added to the cell cover as shown by
embossing or equivalent. Letter size shall be 3/32 ± 1/32 inch.
REQUIREMENTS:
Nomenclature:
Battery, Rechargeable, Cell
Rated Capacity:
5.5 ampere-hours
Voltage (Nominal)
1.2 volts
Discharge
Cut Off
Capacity (AH)
Test
Rate (Amps)
Voltage (V)
Minimum
Capacity
5.5
0.958
5.5
Cycle Life
Normal Rate
5.5
0.958
5.0
1.831/
High Rate
55.0
0.765
Vibration
1.1
1.0
5.5
Altitude
5.5
0.958
4.6
Humidity and Charge Retention
5.5
0.958
4.1
3
