INCH-POUND
MIL-PRF-49450/7B(CR)
9 October 1997
SUPERSEDING
MIL-B-9450/7A (ER)
18 June 1987
PERFORMANCE SPECIFICATION SHEET
BATTERY, RECHARGEABLE, NICKEL-CADMIUM, VENTED, AIRCRAFT
BB-716/A, CELL
This specification is approved for use within CECOM, Department of the Army, and is available
for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-PRF-49450 listed in that issue of the Department of Defense Index of
Specifications and Standards (DoDISS) specified in the solicitation.
BATTERY, RECHARGEABLE (CELL)
(NSN)
PART OF BB-716/A
4.090 MAXIMUM
5.5 AH/ 1HR/ 80 F/ 0.95 V
OVERALL HEIGHT
(CONTRACT NUMBER)
(MANUFACTURER'S PART NO.)
3.700 + .020
TOP OF TERMINAL
SHOULDER
+ .030
4.0000
- .073
TOP OF CELL
TERMINAL
2.60 MAXIMUM
HEIGHT OF
CELL PLATES
2.170 + .025
49450-2
FIGURE 1. Markings and dimensions of cell.
AMSC N/A:
1of 4
FSC 6140
DISTRIBUTION STATEMENT A: Approved for public release; distribution is unlimited.
