INCH-POUND
MIL-PRF-49450/4A(CR)
9 October 1997
SUPERSEDING
MIL-B-49450/4 (ER)
16 January 1987
PERFORMANCE SPECIFICATION SHEET
BATTERY, RECHARGEABLE, NICKEL-CADMIUM, VENTED, AIRCRAFT,
BB-716/A, CELL VENT ASSEMBLY
This specification is approved for use by the USACECOM, Department of the Army, and is
available for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and the issue of MIL-PRF-49450 in that issue of the Department of Defense Index of
Specifications and Standards (DoDISS) specified in the solicitation.
.500 + .015 D IA
.375 + .030 D IA
SEE NOTE 2
V E N T S L IT
SEE NOTE 3
VENT SLEEVE,
NEOPRENE RUBBER
.782 + .030
SURFACE A
M 49450/4-1
O -R IN G
.250-28 UN F -2A T H R E A D
.105 + .015 D IA
.270 M IN . L E N G T H
C R O S S S E C T IO N
T O P A N D S ID E
49450-3
Figure 1. M49450/4 vent assembly.
AMSC N/A:
1 of 2
FSC 6140
DISTRIBUTION STATEMENT A: Approved for public release; distribution is unlimited.
